Application
It is used for centrifugal pumps, mixers, agitators, reactors and valves
handling mild acids, mild caustics, steam, oils, brine, slurries and water.
Reciprocating plunger pumps for sewage treatment.
Technical Data
| Pressure (bar) | Shaft speed (m/s) | |
|---|---|---|
| Static | 100 | – |
| Rotating | 320 | 10 |
| Reciprocating | 50 | 2 |
| Temperature(°C) -50 to +250 | pH 3-11 | |
Spool Ordering Information
| Size | mm | 3 | 5 | 6 | 6.5 | 8 | 9.5 | 10 | 11 | 12 | 12.5 | 14 | 16 | 19 | 20 | 22 | 25.5 |
| inch | 1/8 | 3/16 | – | 1/4 | 5/16 | 3/8 | – | 7/16 | – | 1/2 | 9/16 | 5/8 | 3/4 | – | – | 1 | |
| Packaged(±5%) | kg | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | – | – | – | – | – | – |
| – | – | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | – | – | – | ||
| – | – | – | – | – | – | – | – | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 |
*customized size and length available on request.
